寸法表 | セラミックベアリング | 持木鋼球軸受株式会社

d	型式	D	B	ｒ(min)
3	CE683	7	2	0.1
	CE693	8	3	0.15
	CE603	9	3	0.15
	CE623	10	4	0.15
	CE633	13	5	0.15
4	CE684	9	2.5	0.1
	CE694	11	4	0.15
	CE604	12	4	0.2
	CE624	13	5	0.2
	CE634	16	5	0.3
5	CE685	11	3	0.15
	CE695	13	4	0.2
	CE605	14	5	0.2
	CE625	16	5	0.3
	CE635	19	6	0.3
6	CE686	13	3.5	0.15
	CE696	15	5	0.2
	CE606	17	6	0.3
	CE626	19	6	0.3
	CE636	22	7	0.3
7	CE687	14	3.5	0.15
	CE697	17	5	0.3
	CE607	19	6	0.3
	CE627	22	7	0.3
	CE637	26	9	0.3
8	CE688	16	4	0.2
	CE698	19	6	0.3
	CE608	22	7	0.3
	CE628	24	8	0.3
	CE638	28	9	0.3
9	CE689	17	4	0.2
	CE699	20	6	0.3
	CE609	24	7	0.3
	CE629	26	8	0.3
	CE639	30	10	0.3

d	型式	D	B	ｒ(min)
10	CE6800	19	5	0.3
	CE6900	22	6	0.3
	CE6000	26	8	0.3
	CE6200	30	9	0.6
	CE6300	35	11	0.6
12	CE6801	21	5	0.3
	CE6901	24	6	0.3
	CE6001	28	8	0.3
	CE6201	32	10	0.6
	CE6301	37	12	1
15	CE6802	24	5	0.3
	CE6902	28	7	0.3
	CE6002	32	9	0.3
	CE6202	35	11	0.6
	CE6302	42	13	1
17	CE6803	28	5	0.3
	CE6903	30	7	0.3
	CE6003	35	10	0.3
	CE6203	40	12	0.6
	CE6303	47	14	1
20	CE6804	32	7	0.3
	CE6904	37	9	0.3
	CE6004	42	12	0.6
	CE6204	47	14	1
	CE6304	52	15	1.1
25	CE6805	37	7	0.3
	CE6905	42	9	0.3
	CE6005	47	12	0.6
	CE6205	52	15	1
	CE6305	62	17	1.1
30	CE6806	42	7	0.3
	CE6906	47	9	0.3
	CE6006	55	13	0.6
	CE6206	62	16	1
	CE6306	72	19	1.1
35	CE6807	47	7	0.3
	CE6907	55	10	0.6
	CE6007	62	14	1
	CE6207	72	17	1.1
40	CE6808	52	7	0.3
	CE6908	62	12	0.6
	CE6008	68	15	1
	CE6208	80	18	1.1
45	CE6809	58	7	0.3
	CE6909	68	12	0.6
	CE6009	75	16	1
	CE6209	85	19	1.1
